Core Router
ASFE7640BBX
The ASFE7640BBX Broadcom Jericho2 Core Router integrated with Ramon Fabric switch AS9926-24DB forms a disaggregated distributed chassis DDC architecture to build a scalable and flexible network infrastructure that provides high throughout bandwidth for routing, packet processing, and efficient traffic management.
Categories: Carrier Access / Core Router / Intel® Xeon®
- High-performance 100GbE core router for telecom and data center applications
- Incorporates Broadcom StrataDNX™ Jericho2 silicon for non-blocking line-rate performance
- High capacity external TCAM (BCM16K) for expandable table sizes and statistics
- Consists of 40 x 100G QSFP28 and 13 x 400G QSFP-DD fabric interfaces
- Front-to-back airflow SKU, carrier grade fan filter
- Hot-swappable, load-sharing, and 1+1 redundant DC-DC/AC-DC PSUs
- 4+1 redundant, hot-swappable fan modules
- Synchronous Ethernet, IEEE 1588v2 PTP, Timing synchronization stack interfaces
- Compact design, 635 mm depth
- High operating temperature, up to 55° C
- Hardware switch pre-loaded with Open Network Install Environment (ONIE) for automated loading of compatible open source and commercial NOS offerings.
