OPEN ARCHITECTURE GPON OLT

ASFG964BBX

The ASFG964BBX is an open GPON OLT featuring 64 GPON ports with 8 x 10/25G SFP28, and 2 x 40G/100G QSFP28 fixed ports. The OLT complies with the ITU-T G.984 GPON standard. All GPON ports operate at wire-speed by default and support standard GPON transceivers. This disaggregated OLT supports redundant hot-swappable PSUs and fans.

Categories: Carrier Access / vOLT / Intel® Xeon®

  • High capacity 64 port GPON OLT for next generation open and disaggregated access network architecture.
  • 2 x QSFP28 switch ports, each supporting 1 x 100 GbE or 1 x 40 GbE, or via breakout cables 2 x 50 GbE, 4 x 25 GbE, or 4 x 10 GbE.
  • Layer 2 or Layer 3 forwarding at 300 Gbps (full duplex).
  • Supports front-to-back airflow SKU.
  • All ports on front; PSUs and fans accessible from rear.
  • Hot-swappable, load-sharing, and redundant AC or DC PSUs.
  • 3+1 redundant, hot-swappable fan modules.
  • Hardware switch pre-loaded with Open Network Install Environment (ONIE) for automated loading of compatible open source and commercial NOS offerings.
  • Compatible with Netsia SEBA+

SPECIFICATION

Processor: Intel® Pentium® Processor D-1519 4 cores 1.5 GHz DDR4: 8 GB x 2 SO-DIMM SATA M.2 SSD: 32GB x 1

Service Ports: 64 x GPON ports, 8 x 10G/25G SFP28 ports, 2 x 40G/100G QSFP28 ports

Switch Silicon: BCM88470 Qumran AX

Switching Capability: 300 Gbps full duplex

Dimensions (WxDxH): 477 × 600 x 89 mm (18.78 x 23.62 x 3.50 in)

Weight: 16.51 kg (36.39 lb)

Operating Temperature: 0°C to 40°C (32°F to 104°F)

Software: Open Network Install Environment (ONIE)
