Edge Server

SAF6101I

The Edge Server platform is an ideal solution for edge computing applications, where cloud-based IaaS, PaaS, and SaaS services can be extended out to the network edge, close to the source of the data. This delivers improved performance, requires less bandwidth, and reduces latency. Deployed in SD-WAN or uCPE applications, the SAF6101I Edge Server provides increased agility and reduces both CAPEX and OPEX.

Categories: Edge Server / Intel® / Xeon® / 5G WAN / Wifi 5

Get a feel for what it’s like in 3D

Click, Drag, Scroll-in and out the image to view.

SPECS

Processor: Intel® Xeon® D-1700 processor. Default D-1749NT (10C/20T, 3.0 GHz, 90 W)

Memory: 6 x DDR4 2400-2933MHz RDIMM slots, 3 channels. Max support 256GB

Networking: 2 x 25G SFP28 (2 PFs, 64 VFs, 512 queues, SR-IOV, VEB, EVB, DCB)

Dimensions: (WxDxH) 442 x 540 x 44 mm (17.4 x 21.26 x 1.73 in.)

Weight: 9.82kg (21.64 lb), with 2 PSUs and 6 fans installed

OS Support: Pre-installed Ubuntu Linux Server 16.04 LTS

  • Intel® Xeon® D-1700 processor with 6 x DDR4 RDIMM memory slots, maximum 2933 MHz, 256GB
  • Local Storage Options: 1 x eMMC, 1 x 2.5″ SATA SSD, 1 x M.2 PCIe/SATA SSD
  • 2 x 25G SFP28 ports, 8 x 1000BASE-T RJ-45 PoE ports
  • 2 x PCIe slots, Gen. 4 x8 for add-in cards (up to 225 W power)
  • 1 x OCP 3.0 SFF slot for network interface expansion
  • 3 x M.2 slots
  • Wireless Options:
    • 5G NR M.2 module, with 4×4 MIMO external antennas
      Wi-Fi 5 dual-band, concurrent, with 2 sets of 2×2 external antennas
  • Dual redundant, hot-swappable AC PSUs
  • Remote management through a Baseboard Management Controller (BMC)
